Magnetic Switch
Item No:LK-150S

Magnetic Switch

File download

Item No. LK-150S

• Contact Rating: 0.2A 50VDC
• Contact capacity: 8W
• Operating Distance: 28 mm (cc)
• Life Expectancy: over 1 million cycles at 0.5A @12VDC
• Magnet Used: Nd FeB N35


With a contact rating of 0.2A at 50VDC, the Magnetic Switch is capable of handling low voltage currents efficiently. This enables it to control the flow of electricity in circuits and devices, providing reliable switching and connectivity.

The contact capacity of 8W allows the Magnetic Switch to handle power transmission effectively. It is designed to manage the transfer of electrical energy, ensuring efficient power delivery and preventing excessive power dissipation or damage to connected components.

The operating distance of 28 mm (cc) provides sufficient space for magnetic sensing. This means that the Magnetic Switch can detect and respond to the presence of magnetic fields within its range, enabling precise control and activation of various functions in a system.

The Magnetic Switch boasts an impressive life expectancy, with the ability to withstand over 1 million cycles at 0.5A @12VDC. This durability ensures long-lasting performance and reliability, even in applications that require frequent switching or extended operation.
